TRAILER MOUNTED LIFT
LIFT, BOOM TRAILER 50'
 Image for reference only   Click on above thumbnails for alternate view | |
Model: TZ50
Daily: $360.00
Weekly: $1,200.00
Monthly: $2,400.00
Additional Information
- Working height* 55 ft
- Platform height 49.5 ft
- Horizontal reach 29 ft
- Clear out reach 23 ft
- Up and over clearance 22 ft
- Platform length 2 ft 3 in
- Platform width 3 ft 8 in
- Height - stowed 6 ft 10 in
- Length - stowed 23 ft 6 in
- Width - stowed 5 ft 6 in
- Ground clearance 10 in
- Length - outrigger footprint 14 ft 4 in
- Width - outrigger footprint 14 ft 4 in
- Lift capacity (ANSI, CSA) - rotating platform 500 lbs
- Total Weight 4,400 lbs.
- Self leveling platform standard
- Platform rotation option 90° mechanical
- AC power to platform standard
- Turntable rotation 359° non-continuous
- Outrigger leveling capability 10° (17% grade)
- Towing speed rate 60 mph
- Tongue weight - 400 lbs
- Surge and parking brakes standard
- Controls variable speed system
- Tire size ST 225/75 R15
- Coupler 2 in
- Power source 24 V DC
- Optional Drive:
- Driving on a slope
- Determine the uphill, downhill and side slope
- ratings for the machine and determine the slope
- grade.
- Maximum slope rating,
- tongue/hitch uphill, stowed
- position : 20% (11°)
- Maximum slope rating,
- tongue/hitch downhill, stowed
- position: 20% (11°)
- Maximum side slope rating,
- stowed position: 20% (11°)
- Note: Slope rating is subject to ground conditions
- and adequate traction.
